Name: inteliPhy Monitor Analyzer Compact 0U with power supply 70W (R837016) - Synge Inc.
SKU: R837016

inteliPhy Monitor Analyzer Compact 0U with power supply 70W (R837016)

Analyzer to be mounted in 19" network cabinets. Features LCD display and Ethernet interface. Controls up to 42 sensor bars.

Environmental Characteristics

Operation temperature	0 °C to +40 °C / +32 °F to +104 °F
Altitude standard	IEC 60721-3-3 Class 3K1
Relative Humidity	0% - 95% non-condensing
Environment	WEEE, ROHS, REACH
Vibration and shock	Stationary and non-stationary vibration, including shock
Vibration and shock standard	IEC 60721-3-3 Class 3M1

Mechanical Data

Technical Data

Protocols	Ethernet, TCP/IP, SNMPv1, SNMPv2, SNMPv3
User interfaces	3 x LED, Backlit LCD display 2 x 40 characters, 1 x function button, 1 x reset button
EMC	2004 / 108 / EC
Interface	1 x Bus cable, 1 x Ethernet, 2 x USB host, 1 x RS-232, 1 x rack lamp
