VARIOline, 12x Singlemode OS2 G.657.A1, E-2000-Simplex, Grade C, APC, Fan-out 3U FiberModul- E-2000-Simplex, Grade C, APC, Fan-out3U FiberModul, Indoor cable, Eca (LSZH), 40m (R877377)

Both sides fitted with E-2000™ APC 8° connectors. Pulling tube (IP67) included.
Connector color: green.
Fiber: SM E9/125 G.652.D/G.657.A1 (OS1, OS2).
Fan-out length: 735 mm (3U)

SKU: R877377 Categories: , , ,
Mechanical Data

Cable Length

40.0 m / 131 ft
Technical Data

Cable type

VARIOline cable
Cable design

In&outdoor
Fiber type

Singlemode (SM)
Fiber count

12
Outer sheath material

UV stable FRLSZH
Cable sheath characteristics

Cable, water-tight

Cable, metal-free

zero-halogen
Conductor type FO

loose tube, gel-filled
Fiber class

G.657.A1 (covers G.652.D, OS1, OS2)
Fiber diameter

E09 / 125 µm
Number of connectors (A)

12
Number of connectors (B)

12
Cable overall diameter

6mm
Connector type (A)

E-2000™
Connector type (B)

E-2000™
Connector color (A)

green
Connector color (B)

green
Lever- / frame-coding (A)

Color
Lever color (A)

green
Lever- / frame-coding (B)

Color
Lever color (B)

green
Polishing plug (A)

APC 8°
Polishing plug (B)

APC 8°
Protection class IP (A)

IP 20
Protection class IP (B)

IP 20
Return loss grade RL (A)

1
Protection class IP

IP 20 (Protection against contact)

IP 67 (correlates to NEMA 6P)
Return loss grade RL (B)

1
Attenuation grade IL (A)

C
Attenuation grade IL (B)

C
Connector class

connector

Installation instructions

 Download
